Guitar tab is a six-line diagram where each line is a string and the numbers on the lines tell you which fret to press. It shows you exactly where to put your fingers without requiring you to read standard notation. That is why so many players learn songs from tab first: you do not need to know note names or how to read a staff to follow it. Here is how the six lines and the numbers work, how to read chords and single notes, what the technique symbols mean, and the one thing plain tab does not tell you.
The six lines and the numbers
Guitar tab has six horizontal lines, one for each string of the guitar, and the numbers on those lines are fret positions. The bottom line is the low E string, the thickest one, and the top line is the high E, the thinnest. A number sitting on a line tells you to press that fret on that string, so a 3 on the bottom line means press the third fret of the low E. A 0 means play the string open, with no finger pressing down. Numbers stacked vertically are played together, as a chord, and numbers read left to right are played in sequence, one after another. This is the key difference from a standard staff, where the lines represent pitches and where a note sits tells you which note it is. On a staff the lines are notes; on tab the lines are strings and the numbers point your fingers to the frets. If you want the formal definition, see what is tablature, and for the contrast with the five-line staff, see how to read sheet music.
Reading chords and single notes
The layout tells you whether to strum a chord or play a single line: numbers stacked in a vertical column are struck together as a chord, while numbers spread out horizontally are a melody or riff played one note at a time. Take an open E-minor shape as a tiny worked example. You would see the six strings with a 0 on the low E, a 2 on the A string, a 2 on the D string, and 0 on the G, B, and high E strings, all lined up in one vertical column. Because they share a column, you fret the two second-fret notes and strum all six strings at once. If those same numbers were instead written out left to right, you would pick them individually, sounding the open low E, then the A-string second fret, and so on across the beat. Same numbers, different spacing, completely different sound: vertical means play at once, horizontal means play in order.
The technique symbols
Beyond the fret numbers, tab uses a small set of letters and marks between or beside the numbers to tell you how to play a note, not just where. These are the common ones.
- h is a hammer-on: sound the next, higher note by tapping a finger down onto the fret without picking again.
- p is a pull-off: the reverse move, pulling a finger off to sound a lower note that is already fretted or open.
- / is a slide up: pick the first note and slide your finger up to a higher fret.
- \ is a slide down: pick the first note and slide down to a lower fret.
- b is a bend: push the string sideways to raise its pitch.
- r is a release: let a bend back down to the original pitch.
- ~ is vibrato: wiggle the fretting finger to make the note waver.
- x is a muted or dead note: a percussive click with no clear pitch, made by damping the string.
- PM is a palm mute: rest the picking hand on the strings near the bridge to deaden the sound.
What tab does not show
Standard guitar tab usually does not show rhythm or note durations reliably, and that is its main limitation. Plain tab tells you which frets to play and in what order, but not how long to hold each note or where the beats fall, so in practice you often need to already know how the song goes to play it correctly from tab alone. There are exceptions: rhythm tab adds stems and flags above the numbers to mark durations, and tab is frequently paired with a standard staff so the notation carries the timing while the tab carries the fingering. A Guitar Pro file solves this completely, storing full rhythm alongside the tab and playing it back so you can hear the timing, and full standard notation does the same. If a tab feels ambiguous, the missing piece is almost always the rhythm.
Getting tab for any song
If the song you want is not already tabbed out somewhere, you can generate tab straight from the recording. This is where Songscription helps: it transcribes a guitar recording into tab plus standard notation, so you get the fingering and the rhythm together, and it exports to Guitar Pro for playback and further editing. You upload a file or paste a link, and it produces an editable score you can adjust before you export. For a deeper walkthrough of turning audio into tab, see our guide on audio to guitar tabs, and for how the options compare, see the best AI guitar tab generators. If you are after the chord shapes rather than a full tab, finding guitar chords for any song covers that path.
Frequently Asked Questions
How do you read guitar tab?
Read guitar tab as six horizontal lines, one for each string, with the bottom line being the low E string and the top line the high E. A number on a line tells you which fret to press on that string, and 0 means play the open string. Numbers stacked vertically are played together as a chord, and numbers read left to right are played in sequence.
What do the numbers on guitar tab mean?
The numbers are fret positions, not pitches. A number sitting on a line means press that fret on that string, so a 3 on the bottom line means press the third fret of the low E string. A 0 means play the string open, with no finger pressing down. The number tells you where to put your finger, not which note letter you are playing.
Does guitar tab show rhythm?
Standard guitar tab usually does not show rhythm or note durations reliably. It tells you which frets to play and in what order, but not how long to hold each note, so you often need to already know how the song sounds. Rhythm tab, or tab paired with a standard staff or a Guitar Pro file, adds the timing that plain tab leaves out.
What does h, p, and / mean in guitar tab?
In guitar tab, h means a hammer-on, where you sound the next note by tapping a finger down without picking again. The letter p means a pull-off, the reverse move where you pull a finger off to sound a lower note. A forward slash means slide up to a higher fret, and a backslash means slide down to a lower one.
Want tab for a song you cannot find? Songscription transcribes a guitar recording into tab plus standard notation and exports Guitar Pro, so you get the fingering and the rhythm from a single upload.
